Input Voltage:
|
90-260V, 50-60 Hz
|
|
Maximum ambient Temp:
|
-30°C / 86°F, 50°C / 122°F
|
|
Strobe Tube LEDs
|
144*5W 3535 6500K LEDs (CW+WW 2IN1 LED optional)
|
|
Strobe Panel LEDs
|
480x0.5W 5050 RGB 3in1 LEDs, 20 Segments
|
|
Max Power :
|
1000W
|
|
Protocol:
|
USITT DMX-512, RDM, 2.4 GHz W-DMX＆#8482; (optional)
|
|
Channels:
|
8CH / 17CH / 69CH, 3 channel modes optional
|
|
Tilt movement:
|
185°(8-16bit fine), Position Feedback.
|
|
Advanced moving system:
|
Scan position memory, auto reposition after unexpected movement
|
|
fast, stable and quiet, auto repositioning
|
|
Strobe:
|
Variable from 1-25 flashes or random strobe
|
|
Control Mode
|
DMX512, master-slave and sound activated or auto operation
|
|
Dimming:
|
0-100% Smooth linear LED dimmer
|
|
Internal Effects:
|
LED Macro Effects
|
|
Controls:
|
LCD display with 4 touch buttons
|
|
|
LCD display switch-off automatically after 60 seconds
|
|
Cooling System
|
Lower noise and efficient waterproof FAN cooling system
|
|
Power Connectors:
|
PowerCon＆#8482; compatible in/out power connectors
|
|
DMX Connectors:
|
3-pin DMX input/output (5-pin DMX is available)
|
|
Light Housing:
|
Pure aluminum casting waterproof housing
|
|
Use
|
IP20 for stage, event, DJ shows, etc
|
|
More effects:
|
When combined, these components deliver an astonishing output exceeding 80,000 total lumens.
|
|
|
|
includes a library of customizable RGB and CW strobe effects along with variable dimming modes and curves for quick programming
|
